LED line Multipower 100W 12V power supply is designed for use in advanced installations based on LED strips. The idea of the power supply is to control individual lighting sections or LED light sources simultaneously or separately, depending on the user’s preferences.

The power supply has a very slim shape, allowing for installation even in hard-to-reach places. Installing the power supply is very easy thanks to the integrated Plug&Play system. Mounting and connecting the power supply does not require additional wiring. All components of the power supply have DuPoint connectors that operate on the Plug&Play principle.

• The power supply’s design, with a depth of only 18-20 mm, allows for easy concealment during installation.
• The product has dimensions: 147 mm x 55 mm x 18 mm.
• Output voltage: 12V. The power supply has a power of 100W and 7 output channels for sensors.

The LED line Multipower power supply allows for many possibilities – controlling each channel of the power supply separately or collectively for the entire power supply and all its circuits simultaneously, through one selected sensor. The installation of sensors does not require additional wiring. Sensors are integrated with the cable and ready to be connected directly to the power supply and the LED light source. Controlling all channels of the power supply simultaneously can be done through one of the selected sensors on the Master channel.

Controlling individual channels of the power supply is done by using the appropriate sensor on each output channel of the power supply. There is a possibility of pairing sensors. For example, a sensor can be installed on the master channel, which will play a supervisory role in the operation of the power supply, working with sensors installed on each output channel of the power supply.

The power supplies have protection against short circuits, overloads, and surges. They are ideal for powering low-voltage installations with low power consumption. There is also the possibility of mounting the power supply on flammable surfaces.

The product has obtained certifications: CE, LVD EN62368-1, EMC EN55032, RoHS, CCC

The power supply is intended for indoor use. The product’s ingress protection class – IP20. The product housing is made of polycarbonate. To connect the power supply to the network, a separately sold power cable is required.

The product comes with a 3-year manufacturer’s warranty.
